Product Details:
Payment & Shipping Terms:
|
| Product Name: | Manufacture Fitting Copper 90 Degree Elbow Seamless Pipe Fittings | Size:: | 1/2''-48 '' |
|---|---|---|---|
| Degree: | 90 Degree | Application:: | Connect Pipe Lining |
| Packaging:: | Pallet/ Wooden Box | Of Copper Pipe Fittings:: | ASMStandard E |
| Head Code:: | Round | ||
| Highlight: | 1/2 carbon steel 90 degree elbow,din carbon steel 90 degree elbow,seam 90 degree elbow carbon steel |
||
1/2 Din copper 90 Degree Elbow Seam Type
ASME B16.9 elbow has been produced by the pipe . Firstly, we need cut the pipe into piece and then we put the
elbow om the induction hot forming elbow machine . After forming the copper elbow and we need to sizing
the copper elbow and after we need d beveling , shot blasting , painting ,marking and package . Then the
whole process production line will be finished . For the different size and thickness elbow ,we can get from the
mandrel . Then size different the mandrel different . The thickness is different and the mandrel is also different .
Different bend radius needs different mandrel . So producing ASME B16.9 elbow needs many mandrels for different model.
|
STANDARD
|
ASTM / JIS / DIN / BS / GB/GOST
|
|
|
MODEL
|
1.Tee(Straight and Reducing) 2.180 DEG Return
|
|
|
3.Elbow (45/90/180 DEG) 4.Cap
|
||
|
5. Reducer(Concentric and Eccentric)
|
||
|
TYPE
|
Seam Or Seamless
|
|
|
ELBOW DEGREE
|
45 degree, 90 degree, 180 degree
|
|
|
WALL THICKNESS
|
SCH5S,SCH10S,SCH10,SCH20,SCH30,SCH40,STD,XS,SCH60,
|
|
|
SCH80,SCH100,SCH120,SCH140,SCH160,XXS,2MM
|
||
|
SIZE
|
1/2"-48"(Dn15-Dn1200)
|
|
technical requirements
1. Since most pipe fittings are used for welding, in order to improve welding quality, the ends are beveled with a certain Angle and a certain edge. This requirement is also strict.The surface mass and mechanical properties are basically the same as the pipe.For the convenience of welding, the fittings are the same type of steel as the connected pipe.
2, that is, all the pipe fittings have to go through the surface treatment, the inner and outer surface of the oxidized iron sheet through the peening treatment, and then painted with anti-corrosion paint.This is for export needs, moreover, in the domestic is also for the convenience of transportation to prevent corrosion and oxidation, must do this aspect of the work.
3, is the requirement for packaging for small pipe fittings, such as exports, we need to make wooden cases, about 1 cubic meter, stipulated that the number of elbows in this kind of box can not exceed 1 ton, the standard allows the set, that is, large set small, but the total weight generally can not exceed 1 ton.For large pieces of y you need a single package, like 24 "you need a single package.Another is the packaging mark, mark is to indicate the size, steel, batch number, manufacturer's trademark.
