Non Oiled Large Diameter Spiral Steel Pipe SSAW Tube For Drilling Construction

Large Image : Non Oiled Large Diameter Spiral Steel Pipe SSAW Tube For Drilling Construction

Product Details:

Place of Origin:	china
Brand Name:	junxi
Certification:	iso
Model Number:	ssaw

Payment & Shipping Terms:

Minimum Order Quantity:	1ton
Price:	Can discuss
Packaging Details:	wooden case
Delivery Time:	15~25Can discuss
Payment Terms:	L/C, D/A, D/P, T/T
Supply Ability:	10000000ton

Contact Now

Detailed Product Description

Place Of Origin:	China	Outer Diameter:	21.2 - 273 Mm, 21.3-273 Mm
Tolerance:	±1%	Oiled Or Non-oiled:	Non-oiled
Delivery Time:	15-25 Days	Type:	Spiral
Name:	Spiral Steel Pipe	Material:	Carbon Steel
Highlight:	Drilling Construction SSAW Tube , Drilling Construction Spiral Steel Pipe , Non Oiled Spiral Steel Pipe

Large diameter spiral steel pipe tube SSAW steel pipes for drilling construction

Spiral welded pipe.

Compared with the straight seam welded pipe, the spiral welded pipe has higher strength and larger diameter. The production standard of the spiral welded pipe is more than that of the straight seam welded pipe. Mainly used in steel structure engineering, machinery manufacturing, construction water, oil pipelines and other low-pressure fluid pipelines, and can also be used in piling, structure and other construction fields

The spiral steel pipe is a spiral seam steel pipe with a steel coiled plate as a raw material, which is often extruded and formed
by welding with an automatic double-wire submerged arc welding process. The spiral steel pipe feeds the strip steel into the
welded pipe unit, and after being rolled by multiple rollers, the strip steel is gradually rolled up to form a round tube blank
with an open gap. 3mm, and make the two ends of the welding port flush.

Main Application:

1. Piling pipe;

2. Construction;

3. Water, Oil, Gas transportation;

Feature	seamless	welded, seamed
Types	hot rolled seamless carbon steel pipe cold rolled seamless carbon steel pipe cold drawn seamless carbon steel pipe	Electric-Resistance Welded Pipe Longitudinal Welded Pipe Spiral Welded Pipe
Standard	astm a53, a333, a335, a355, a312, a179, a106, a106b, a105, a192, a519, a210, a671, a672, sa213 jis G3445/3454/3455/3441/3444 *din17175, din1629, din1615, din2458, en10210	a672, a795, a252, a53b, a53, a135, a500
Technique	cold rolled, hot rolled, cold drawn	erw straight seam or spiral seam(efw available)
Outer Diameter	50mm-630mm (1.96''-24.8'' hot rolled seamless steel pipe); 5mm-100mm (0.19''-3.93'' cold rolled/drawn seamless steel pipe)	20mm-600mm (0.78''- 23.6'' straight seam weld steel pipe); 219mm-2020mm (8.62''-79.52'' spiral seam weld steel pipe).
Wall Thickness	3mm-20mm (0.11''-0.78'' hot rolled seamless steel pipe); 0.5mm-3mm (0.01''-0.11'' cold rolled/drawn seamless steel pipe).	1.0mm-12mm (0.03''-0.47'' straight seam weld steel pipe); 3mm-16mm (0.11''-0.62'' spiral seam weld steel pipe).
Length	500mm-13000mm (19.6''-511.8'' or random length)	300mm-12000mm(11.8''-472.4'' or random length)
Grade	4140/4145/4130/4135/3087, ss400, c45, s235, s275jr, s355jr, s355j2h, p235gh tc2, p235 tr1, p235 tr2, sae1040/1020/1010/1070/1015/1018, stpg307, 40cr, 34crmo4, 20gr, 37mn, 16mnr, 20#, q345c, q195, q235c, 195c, s45c, st37/45/20/52/33 etc	sa 53 gr b, p91, q235b, q345b, q235, q195, st37, st44, s355, s135, s185, s235jr, s275jr, s355jr, etc
Shape	round, square, rectangular
Pipe Ends	plain ends, beveled ends etc
Surface Treatment	shot blasting/galvanized/painted as customer needs

Non Oiled Large Diameter Spiral Steel Pipe SSAW Tube For Drilling Construction 0
