Pneumatic Top Guided Industrial Control Valves Single Seated Steam

Pneumatic Top Guided Industrial Control Valves Single Seated Steam
Pneumatic Top Guided Industrial Control Valves Single Seated Steam

Large Image :  Pneumatic Top Guided Industrial Control Valves Single Seated Steam

Product Details:
Place of Origin: China
Brand Name: JUNXI
Certification: CE
Model Number: Valve Gate
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Discussable
Packaging Details: In wooden box
Delivery Time: 5-8 work days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 100 set/days
Detailed Product Description
Material: Carbon Steel Technics: Forged
Shape: Control Valve Connection: Welding
Type: Valve Color: White Or Customized
Application: Oil/water Size: DN20-DN400
Struction: Two Ways
High Light:

pneumatic top guided industrial control valves

,

single seated industrial control valves

,

pneumatic top guided steam control valves

Pneumatic Top-Guided Single-Seated Control Valves

Steam Control Valves



Standard Industry Application
Product Name
Size
ANSI Class
Standard Materials
Temperature Range
Globe Control Valve
1/2" to 12"
125 to 300
Cast Iron, Carbon Steel, Stainless Steel, Monel, Hastelloy, (Special Materials on Request)
'-325 to 842oF (-196 to 450oC)
3-Way Control Valve
1/2" to 6"
150 to 300
Carbon Steel, Stainless Steel
-325 to 842oF (-196 to 450oC)
Cryogenic Control Valve
1/2" to 10"
150 to 900
Cast Stainless Steel (A351 CF8)
-325 to 149oF (-196 to 65oC)
Top-Entry Cryogenic Control Valve
1" to 6"
150 to 600
Cast Stainless Steel (A351 CF8)
-425 to 149oF (-254 to 65oC
On/Off Globe Valve
1/2" to 4"
150 to 300
Carbon Steel, Stainless Steel
58 to 482oF (-50 to 250oC)


Model HSC Cage Type Single Seated Control Valves are designed for high differential pressure heavyduty service where
flashing/cavitation may occur. Further, they are ideal for preventing erosion from the valve body, because their guides are sturdy and the valve body is protected by a cage. The compact valve body, having an S-shaped flow passage that features low pressure loss, allows a large flowcapacity and rangeability.
The valve plug is highly vibration-resistant as it is held by a top guide section which has a large sliding area. The flow shutoff performance complies with the IEC or JIS Standards. The actuator, integrated with simplest mechanisms, utilizes a compact yet powerful diaphragm actuator loaded with multiple springs.
The model HSC Control Valves are widely applicable for reliable control of flows in high- or lowtemperature, high differentialpressure process lines.


Product Picture

Pneumatic Top Guided Industrial Control Valves Single Seated Steam 0
