Flange Forged Wcb Gate Valve 8 Inch Actuator Electrical Water Industrial Control Valves

Flange Forged Wcb Gate Valve 8 Inch Actuator Electrical Water Industrial Control Valves
Flange Forged Wcb Gate Valve 8 Inch Actuator Electrical Water Industrial Control Valves

Large Image :  Flange Forged Wcb Gate Valve 8 Inch Actuator Electrical Water Industrial Control Valves

Product Details:
Place of Origin: hebei
Brand Name: junxi
Payment & Shipping Terms:
Minimum Order Quantity: Can discuss
Price: Can discuss
Delivery Time: 15~25
Payment Terms: L/C, T/T
Supply Ability: 1000
Detailed Product Description
Media: Water,Oil,Gas Power: Manual,Handwheel Operated,electric,Gear Operated
Structure: Gate Valve Port Size: DN40-DN1000
Material: Stainless Steel Pressure: PN16/10
Structure Length: ASME B16.10
High Light:

8 inch industrial control valves

,

wcb industrial control valves

,

forged wcb gate valve

Flange forged wcb Gate Valve 8 Inch Actuator Electrical Water



Specification Details

Design Std:EN 1171

Size:DN40--DN1000

Pressure Rating: PN16,PN10

Seat: NBR,EPDM, VITON,PTFE,NEOPRENE

Face to Face: EN 558 Series 14(DIN 3202 F4)

Pressure Testing:DIN EN593/DIN EN12266-1

Body/Bonnet: Ductile iron EN-GJS-500-7/EN 1563

Flange Ends: DIN EN1092-2/Type B

Working temperature:-10 to +120℃



Gate Valve:

Standard

DIN 3352-F4 ,DIN 3352-F5, BS5163, AWWA C509 ,AWWA C515

Flange drilling is according to DIN2501, BS4504 and ANSI B16.1 PN10,PN16,PN25

Type Flanged End , Socked End ,Mechanical Joint, non rising stem / rising stem
Material

Body: Ductile iron GGG40/50 or Cast IronGG25

Wedge : Ductile iron GGG40/50+EPDM/NBR or metal seated

Stem: stainless steel 2Cr13 , SS304,SS316

Bolt and Nuts : Carbon Steel with zinc plated or SS304,316

Coating Internal and external with fusion bonded epoxy coating min250μm




Design Feature

1: Full bore or reduced bore
2: Two-Piece downstream sealing
3: Fire safe design(API 607)
4: Blowout-proof system
5: Anti-static design
6: Fugitive emission testing(optional)







Flange forged wcb Gate valve description:

-Design and manufacturing standards, in accordance with the: ASME B16.34, API6D;

-Structure length according to: ASME B16.10;

-The flange end size according to: ASME B16.5

-Threaded end size in accordance with the: ANSI B1.20.1;

-The butt end size in accordance with the: ANSI B16.25

-Socket size in accordance with the: ANSI B16.11

-Inspection and testing in accordance with the: API598



-An optional sealing surface material:13 cr alloy steel (code H)Carbide STL code (Y)Can choose other special sealing materials according to customer's requirement.



-The main alternative material:
Carbon steel class: WCB, WCC, A105, etc
Class: stainless steel 304,316,304 L, 316 L, CF8, CF8M, CF3, CF3M, CF8C and duplex stainless steel, etc.
Class: low-temperature steel LF2, LCC, LCB, etc
Chrome molybdenum steel types: WC5 WC6, WC9, C5, etc



Flange Forged Wcb Gate Valve 8 Inch Actuator Electrical Water Industrial Control Valves 0
