Castings Forgings Portable Pipe Cutting Beveling Machine CE

Castings Forgings Portable Pipe Cutting Beveling Machine CE
Castings Forgings Portable Pipe Cutting Beveling Machine CE
video play

Large Image :  Castings Forgings Portable Pipe Cutting Beveling Machine CE

Product Details:
Place of Origin: China
Payment & Shipping Terms:
Minimum Order Quantity: 1 SET
Price: negotiable
Packaging Details: plastic wrapping & wooden box for Hand Portable Pipe Cutting And Beveling Machine
Delivery Time: 20-25 WORK DAYS
Payment Terms: L/C, D/A, D/P, T/T
Supply Ability: 10-15 SET/ MONTH
Detailed Product Description
Cutting Material:: Carbon Steel , Stainless Steel Color:: Green
Type:: Electric Key Selling Points:: High Productivity And High Speed
Application:: Bevel Pipe And Pipe Fitting Use:: Math Pipe And Pipe Fittings
Name: Manual Beveling Machine
High Light:

forgings portable pipe cutting beveling machine

,

ce portable pipe cutting beveling machine

,

castings tube cutting and beveling machine



I. Function Overview

This machine is suitable for small castings, forgings, stampings and other parts and thin-walled, afraid of collision parts surface cleaning, can also be used for some parts surface strengthening cleaning(can not directly clean high temperature parts, with burrs, flying edge parts, otherwise easy to damage the track)

This machine is a good cleaning effect, compact structure, low noise, complete sets of good cleaning equipment, it has the following advantages:

  • The arrangement of the shot blasting chamber body and the shot blasting machine are determined after the computer three-dimensional dynamic blasting simulation.
  • Our blast machine using Japanese technology structure (Q034 inline), with low noise, long service life, etc., can significantly improve the cleaning efficiency, to obtain satisfactory cleaning quality, (by the manufacturer with the A typical material actually adjusted to achieve the best effect of use).
  • Separation device adopts the most advanced international full curtain type pill slag separator, which significantly improves the separation effect.
  • For the cleaning of different workpieces, the demand side must configure special tooling to ensure the best cleaning effect.
  • Reasonable design and compact structure.
  • The use of the company's pulse type bag dust collector, dust removal effect is good, long life, easy maintenance.



II. Technical specifications

No. Item Quantity Indicators
1 cleaning workpiece 1 single piece of the heaviest ≤ 15kg
2 cleaning requirements   with GB8923-88 A-B Sa2 1/2 standard
3 Shot blasting machine

Model: Q034

Shot blasting volume: 260kg/min

Blasting speed: ≥7.5m/s

Power: 15kw

4 The use of projectile   Ф0.15~2.5
5 The first time to join the volume of projectiles   0.2 t
6 Bucket elevator

Lifting capacity: 5t/h

Power:1.5kw

7 Screw conveyor 1

conveying capacity: 6t/h

Power: 1.5kw

8 Separator 1

Separation capacity: 56.5t

Separation area wind speed: 4~5m/s

Qualified projectile content in waste material: ≤1%

9 Dust removal system 1

Model: pulse dust collector

Main fan air volume: about 340m³/h

Power: 3kw

10 Total power   about 21.5kw

 Castings Forgings Portable Pipe Cutting Beveling Machine CE 0

2. Company Information:


Name Guozhong International Limited / Huawei pipe fitting machine Co.ltd
Business Type Manufacturer & Trading Company
Main product Cold forming elbow machine, Hot forming elbow machine, Cold forming tee machine, Beveling machine, Shot blasting machine, Marking machine, Sizing machine, Ring rolling machine
Trade Market Mild East, Africa, Eastern Europe, South Asia, Southeast Asia, South America
Certificate CE certificate



3. Packaging & Delivery
Castings Forgings Portable Pipe Cutting Beveling Machine CE 1Castings Forgings Portable Pipe Cutting Beveling Machine CE 2
