workbench.
NTSC,and21inzerosetupNTSC.
-GreenField
-BlueField
-RedField
-100%FlatField
-50%FlatField
-0%FlatField
-Multiburst
-60%ReducedLineSweep
-5StepGrayScale
-4.43MHzModulated5Step
-MatrixofCCIR17,CCIR18,
CCIR330,CCIR331,Sin(x)/x,
15kHzSquareWave,Shallow
Ramp,UKITS1,UKITS2
FieldSquareWave
-Bounce
-SMPTEBars
-75%ColorBars
-SNGColorBars
-Convergence
-SafeTitle/SafeArea
-RedField
100IREFlat
50IREFlatField
BlackBurst
5StepGrayScale
Multiburst.
NTC7Combination
FCCComposite
CableMultiburst
CableSweep
Sin(x)/x
MatrixofNTC7Composite,
NTC7Combination,Color
Bars,Sin(x)/x,50IREFlat
Field
-0IRENoBurst
-FieldSquareWave
-Bounce
VerticalIntervalTestSignals(VITS)maybe
includedonFlat
FieldandMatrixtestsignalsinsinglestandard
configurations.
Itmaybeconfiguredformultiplesignal
standardsby
selectingupto26signalsasausersignalset.
Uptoeightmessages,eachcontainingtwo16-
characterlines,maybestoredforlaterrecall.
Onemessagemaybeinsertedintothevideo
testsignal,anduptofourmaybecycledinto
thetestsignalinacontinuousloop(displaying
eachmessagefor1
to9seconds).Themessagemaybepositioned
anywherewithinthesafe-titlearea.CreatingID
textisfastandsimpleusingthealphanumeric
keypadnotediousscrollingthroughthe
alphabetwitharrowkeysforeachcharacterin
theID
message.JusttypeinamessagebacklitLCD
display.
Uptofourcompletefrontpanelconfigurations,
includingmenuselections,currenttext
message,andcycleinformationmaybestored
forlaterrecall.Thirteenaudiotonefrequencies
(from50Hzto20kHz)oranaudiosweepare
selectablefromtheTonemenu.Fourtone
levels(?10,0,+4,and+8dBu)are
Availableaswell.Specialtonefrequenciesand
levelswithin
theserangesmaybesetupforspecial
applications.Anaudio
clicksequencecanalsobeselectedasanaidin
easilyidentifyingandtracingleftandright.
RequiredDocuments:
OriginalCatalogmustbesubmitted
Distributor/ManufactureAuthorizationLetter
mustbesubmitted
ISOCertificate(Product)
Warranty:OneYearWarranty
