Model: JX Semiconductor Tester
Country of Origin: CHINA
Country of Manufacture: CHINA
Capacitance Range
200pF (0.1pF), 2nF (1pF), 20nF (10pF),200nF
(100pF), 2µF (1nF),20µF (10nF), 200µF
(100nF),2000µF (1µF), 20mF,(10µF)
Capacitance Accuracy
±(0.5% rdg + 1dgt), ±(0.5% rdg + 1dgt),
±(0.5% rdg + 1dgt)
±(0.5% rdg + 1dgt), ±(0.5% rdg + 1dgt),
±(0.5% rdg + 1dgt)
±(1%rdg + 1 dgt), ±(1.5%rdg + 1dgt)
Resistance Range
200Ω (100mΩ), 2kΩ (1Ω), 20kΩ (10Ω),
200kΩ (100Ω)
2MΩ (1kΩ), 20MΩ (10kΩ), 20MΩ (10kΩ)
Resistance Accuracy
±0.75% rdg + 5 dgts, ±2% rdg + 4 dgts, ±0.5%
rdg + 1 dgt
±0.5% rdg + 1 dgt, ±0.5% rdg + 1 dgt, ±0.75%
rdg + 1 dgt
±2.0% rdg + 1 dgt
Standard Accessories :
Power Source: 9V Battery
Display: Min 3 1/2 Digit LCD
Digit Height : 0.8''
Storage Temperature: -4 to 140°F
Dimensions: Approx. 6.88 x 3.25 x 1.5''
Required Documents:
Original Catalog must be submitted
Manufacture Authorization Letter must be
submitted
ISO Certificate (Product)
Warranty: One Year Warranty
