Brand: JX
Model: JX Color TV Trainer with PC Interface
Country of Origin: CHINA
Country of Manufacture: CHINA
Superior quality 21 inch full HD LED Color
Television
- Manual and Remote control operation
- PAL/ NTSC video formats
- Composite video input/ VGA input
- Complete block diagram of a LED TV system
- Complete Driver board/SMPS unit housed in
an enclosed cabinet to protect
it from damages
- Study board indicating various sections of
LED TV along with the test
points and switch faults
- Detachable Driver board/SMPS unit and LED
Display unit
- Easy LVDS cable interface between Driver
board and LED Display unit
- Easy Logic cable interface between Control
panel and Logic board for sensor etc.
- Acrylic Sheet protection for Driver
board/SMPS circuit
- Easy identification of different parts and
components of the system at a glance.
- Easy measurement of voltages and
observation of waveforms on Test points .
- Exhaustive Online Product Tutorials and
video for fault finding of different section of
LED TV training system explaining theory,
circuit, experiments, procedure, typical
waveforms and voltage.
Fault creation by switches and troubleshooting
No soldering/de-soldering is required to
simulate faults
Display Type : LED, HD
Screen Size : not less than 21''
Display Resolution : 1366 X 768 pix or better
Contrast Ratio : Mega Contrast Ration
Display Color : 16.7 Million Display
Viewing Angle : 170º (H) X 160º (V)
Refresh Rate : 50 Hz
Video Interface : Video/VGA In
Audio Interface :RCA L & R
Audio Output Power (RMS) : 5W X 2
Receiving System : PAL BG/I/DK and NTSC
Channel Coverage : VHF; UHF; CATV
Application : TV/ PC Monitor connect
USB : 1 X USB 2.0
HDMI : Yes (1 X HDMI)
Other Connectivity : AV, VGA, Audio In
Composite A/V : Yes
Component Video : Yes
Analog Audio : Yes
Test Points : More than 15
Switched Faults : More than 12
Required Documents:
Original Catalog should be submitted
Manufacture Authorization Letter should be
submitted
ISO Certificate (Product)
Warranty: One Year Warranty
