Brand: JX
Model: JX Analogue Oscilloscope
Country of Origin: CHINA
Country of Manufacture: CHINA
Technical Specification
CRT: 6 inch rectangular screen with internal
gratitude, 8x10div (1div = 1cm)
Display mode: CH1. CH2. ADD, ALT, CHOP
Deflection factor: 5mV/div to 5V/div ±3%.
1mV/div to 1V/div ± 5%(X5).10 steps
Rise time: ≤17.2ns
Max. Input voltage: 250V (DC+AC peak)
≤1KHz
Input coupling: AC. DC. GND
Polarity selection: + or - (CH2 only)
Display mode: 1,10, X-Y
Time Base: 0.2us/div to 0.2s/div,9 ranges
Sweep magnification: X10
Accuracy: ±3%
Trigger mode: NORM , AUTO,TV-V, TV-H
Trigger source: CH1.CH2. VERT. LINE. EXT
Sensitivity and Frequency: 20Hz-
30MHz(VERT)
AUTO. NORM: 0.5div(INT), 0.5Vp-p(EXT)
TV-V, TV-H: At least 1 div or 1 Vp-p
Input impedance: 1MΩ
X-Y Phase difference : ≤3°,DC-50kHz
Calibration waveform: Frequency: 1kHz ±20%,
voltage :0.5V ±10%
Power supply: 220V/110V ± 10%; 50/60HZ
Dimensions: Approx. 310(W) X 130(H) X
370(D)mm
Weight: Approx. 8.5KG
Required Documents:
Original Catalog must be submitted
Manufacture Authorization Letter must be
submitted
ISO Certificate (Product)
Warranty: One Year Warranty
